| X | 16" | 406.4 mm |
| Y | 10" | 254 mm |
| Z | 15.75" | 400.05 mm |
| Auto Threading (Yes/No) | Yes | Yes |
| Submerged (Yes/No) | No | No |
| Control | CNC (CNC (Charmilles)) | CNC (CNC (Charmilles)) |
| Dimensions | 71″ L x 63″ W x 88″ H (approximate) | 71″ L x 63″ W x 88″ H (approximate) |
| Weight | 5,700 lbs (approximate) | 5,700 lbs (approximate) |
These specifications are for refence.
All specs and details are subject to confirmation by the buyer.
Inspections are welcomed and encouraged.
Brand: Charmilles Technologies
Model: Robofil 310
Serial #: 350923
Year: 1995
Specifications:
Machining Stroke (X-Y-Z): 15.7″ x 9.8″ x 15.7″
Machining Stroke (U, V): 15.7″ x 9.8″
Taper Capacity: 0 to 30 Degrees
Maximum Workpiece Size: 33.5″ x 19.7″ x 15.7″
Maximum Workpiece Weight: 2,207 lbs
Wire Diameter Capability: 004″ to .012″
Electrical: 380V/3PH/18 Amps
Approx. Shipping Weight: 5,700 Lbs.
Approx. Shipping Dimensions: 71″ L x 63″ W x 88″ H
Charmilles CNC Control
Auto Wire Threading
14″ Color Graphics Monitor
Remote Hand Pendant
Filtration System
Power Transformer
All available Manuals and O/S Backups
Supplemental blue composite water storage containers (3 avail)
This equipment has been sold. Similar equipment available now is shown below.
