Specification MVP-850
X-axis Travel 850
Y-axis Travel 600
Z-axis Travel 560
Distance from spindle center to table surface (mm) 150-710
Table dimension (mm) 1050 x 600
Max. table load (kgs) 600
Rapid traverse (m/min) 48/48/36
Cutting feedrate (m/min) 1-10
Spindle speed (rpm) 10000 (DDS)
Spindle nose BT-40
Spindle motor (kw) 7.5/11
Tool changer 16 (High speed synchrony changing system)
Machine dimension (mm) 2600x2254x2839
Machine weight (kgs) 5000
