Specification MV-1050
X-axis Travel 1050
Y-axis Travel 600
Z-axis Travel 560
Distance from spindle center 150-710
to table surface (mm)
Table dimension (mm) 1250 x 600
Max. table load (kgs) 800
Rapid traverse (m/min) 36/36/36
Spindle speed (rpm) 8000( Belt)
Spindle nose BT-40
Tool changer 20 (Carrousel type)
Machine dimension (mm) 3000 x 2254 x 2839
Machine weight (kgs) 5300
