Specification HT-630SP
X-axis Travel 1050
Y-axis Travel 900
Z-axis Travel 1000-1350
Distance from spindle center to table surface (mm) 155-1155
Table dimension (mm) 630 x 630
Max. table load (kgs) 1200
Rapid traverse (m/min) 36/36/36
Spindle speed (rpm) 8000 (DDS)
Spindle nose BT-50
Spindle motor (kw) 22/26
Tool changer 60 (Carousal type)
Machine dimension (mm) 6030 x 4000 x 3600
Machine weight (kgs) 27922
