GANESH GTW-16 16” X 40”/ 60” HEAVY DUTY ENGINE LATHE

CAPACITY & DIMENSIONS
Swing over Bed
16″ (410 mm)

Center Height
8 1/6″ (205 mm)

Swing over Cross Slide
9 7/16″ (240 mm)

Swing thru Gap
23 7/16″ (595 mm)

Length of Gap in front of face plate (D1-6 / A1-6)
6 1/8″ / 6 7/8″ (155 mm / 175 mm optional)

Bed casting width / bed casting height
11 13/16″ / 12.20″ (300 mm / 310 mm)

SPINDLE
Spindle Motor Horsepower
7.5 HP

Spindle Speeds – 12 speeds 30 – 2,000 RPM
30 – 2,000 RPM

Spindle Bore
2 1/16″ (52 mm)

Spindle Nose
D1 – 6
A1-6 Optional

Spindle taper in Spindle Nose
MT-6
Morse Taper #6

CARRIAGE
Cross Slide Travel / Cross Slide Width
9″ / 7 3/32″ (230 mm / 180 mm)

Cross Slide Lead Screw Pitch
4TPI

Cross Slide Resolution per division
0.50″ / rev. (on diameters)

Carriage Lead Screw Diameter / Pitch
1 1/4″ / 4 TPI (32 mm / 6 mm pitch)

Feed Rod Dimension
7/8″ hexagon 23 mm hexagon

COMPOUND
Compound Top Slide Trave / Compound Width
4 3/4″ / 4 11/32″ (120 mm / 110 mm)

Cutting Tool Height Maximum
1.0″ x 1.0″ (25 mm x 25 mm)

TAILSTOCK
Quill Diameter
2 1/8″ (54 mm)

Quill Stroke
4 3/4″ (120 mm)

Quill Taper
MT-4
Morse Taper #4

Quill Tang Drive and Drift-Slot for Tailstock
included

Tailstock Body set-over adjustment
±0.04″ ±1 mm

THREAD CUTTING
Thread Cutting Range – 40″ pitches
2 – 56 TPI

Thread Cutting Range – 53 metric pitches
0.4 – 14 mm

Thread Cutting Range – 32 diametral pitches
4 – 32 D.P. (optional)

Thread Cutting Range – 44 module pitches
0.4 – 7 M.P. (optional)

FEEDS
Feeds – Longitudinal – 40 Feeds
0.0012″ – 0.0252″ / rev. (0.032 mm – 0.898 mm/rev.)

Feeds – Cross – 40 Feeds
0.0006″ – 0.0126″/ rev. (0.016 mm – 0.449 mm/rev.)

Feed stop control shaft
4 adjustable automatic feed stops to disengage the longitudinal feed

POWER
Coolant Pump motor
220 vac / 1/8 HP / 3 Phase

Power Requirements
220 vac / 7.5 HP / 3 Phase @ 20 amps
