+ High Quality Meehanite Casting
+ Hardened and ground Turcite® coated bed ways
+ Hardened and ground gears
+ 12-speed geared-head spindle
+ Hardened and ground Camlock Spindle
+ Safety foot brake
+ Safety chuck guard
+ Coolant pump standard
+ Tailstock features a 2-speed quill advance
GTW-22 SERIES MACHINE SPECIFICATIONS:
A full comprehensive quote with additional information is available upon request. All OEM Specs are for reference and should be confirmed by the buyer.
GTW-22 SERIES MACHINE PRICING
GTW-2260 Heavy-Duty 22” X 60” Engine Lathe $33,990.00
60.2” between centers, LxWxH – 120” x 51” x 52”, G.W. 5,850 pounds
GTW-2280 Heavy-Duty 22” X 80” Engine Lathe $35,990.00
80.3” between centers, LxWxH – 140” x 51” x 52”, G.W. 6,173 pounds
GTW-22100 Heavy-Duty 22” X 100” Engine Lathe $38,990.00
100.4” between centers, LxWxH – 160.1” x 51” x 52”, G.W. 6,768 pounds
GTW-22120 Heavy-Duty 22” X 120” Engine Lathe $42,990.00
120.5” between centers, LxWxH – 180.2” x 51” x 52”, G.W. 7,363 pounds
Capacity & Dimensions-
Swing over Bed 22” (560 mm)
Center height 11” (280 mm)
Swing over Cross Slide 14-1/8” (360 mm)
Swing thru Gap 29-3/8” (745 mm)
Length of Gap in front of faceplate, D1-11 6-1/2” (165 mm)
Bed width 16-1/8” (400 mm)
Spindle-
Spindle Motor Horsepower 15-HP 12kw
Spindle speeds – 12-speeds from 15 – 1200 rpm) (High & Low speed range)
Spindle Bore 4-1/8” (105 mm)
Spindle Nose D1-11 Camlock (A1-11 optional)
Spindle taper in spindle nose MT-8 Morse Taper # 8
Spindle taper reduction sleeve provided MT-5 MT-8 to MT-5
Spindle Max weight capacity (Chuck only) 660 lbs. (300 kgs)
Spindle Max weight capacity (Chuck and Tailstock) 1,650 lbs. (750 kgs)
Spindle Max weight capacity (Chuck, Steady Rest and Tailstock) 3,300 lbs. (1,500 kgs)
Carriage -
Cross slide travel 14.96” (380 mm)
Cross slide width 7-3/32” (180 mm)
Cross slide lead screw pitch .200”/rev.
Cross slide resolution per division 0.001” (on diameters)
Carriage lead screw diameter 1-1/2” (38 mm)
Carriage lead screw pitch 4 TPI (6 mm pitch)
Compound- Four T-nut lock-down bolts on compound cross-slide base
Compound top slide travel 10” (255 mm)
Compound top slide width 4-11/32” (110 mm)
Cutting tool height maximum 1.0” x 1.0” 25 mm x 25 mm
Tailstock- (2-speed quill advance) Engraved with inch / metric quill graduations
Quill diameter 2-15/16” (75 mm)
Quill stroke 6-5/16” (160 mm)
Quill taper MT-5 Morse Taper # 5
Quill advance – 2-gear selected advance speeds 1:1 2:1
Tailstock body set-over adjustment ± 0.04” (± 1 mm)
Thread Cutting-
Thread cutting range – 60-inch pitches 2 – 112 TPI 2 – 112 TPI
Thread cutting range – 60-metric pitches 0.2 – 14 mm 0.2 – 14 mm
Thread cutting range – 50-diametral pitches 4 – 112 D.P. 4 – 112 D.P.
Thread cutting range – 50-module pitches 0.2 – 7 M.P. 0.2 – 7 M.P.
Feeds- (with clutched feed shaft for safety)
Feeds – longitudinal - 50 feeds 0.0014” – 0.0387”/rev. 0.037 – 1.04 mm/rev.
Feeds – cross - 50 feeds 0.0007” – 0.01935”/rev. 0.0185” – 0.52 mm/rev.
Power-
Power Requirements 220 vac, 3-Phase, 40 Amps (440 vac optional)
Coolant System 1/8-HP Pump Motor, 5-gallon (20L) tank capacity
Machine Options:
Peace-of-Mind Factory Installation – includes expenses $2,995.00
Taper Attachment Factory Installed $3,995.00
Wiring for 440-volt input voltage (Net Price) $495.00
Micrometer Carriage Stop $295.00
Lead Screw Cover- Factory Installed $1,995.00
JFK Collet Closer P.O.R.
Digital Readout Options Match DRO length to the desired bed-length.
2-Axis 80” Newall Premium DRO’s - installed $4,895.00
2-Axis 100” Newall Premium DRO’s - installed $5,695.00
2-Axis 120” Newall Premium DRO’s - installed $6,395.00
3-Axis readouts and additional FAGOR DRO models are available by request.
Chuck Options
12” 3-Jaw Chuck $1,695.00
16” 4-Jaw Chuck, D1-11 Direct Mount $1,995.00
Tooling and Work-holding:
Heavy Duty Steady Rest –3”-8” capacity w/ Roller Bearings $2,495.00
Heavy Duty Steady Rest –8”-15” capacity w/ Roller Bearings $3,195.00
Live Center MT-5 $1,185.00
Dorian Quick-Change Wedge-Type DA size 4” wide toolpost & 4-toolholders:
2 ea. Turning/Facing toolholder, 2 ea. Boring/Turning/Facing toolholder $2,395.00
INCLUDED WITH MACHINE - A $3,000 VALUE
Steady Rest with Roller Bearings (Capacity 4” – 10”)
Follow Rest
12” Back Plate
Full Length Back Splash Guard
Chuck Guard with Safety Interlock Switch
Foot brake
Machine Leveling Pads
Halogen Work Light (55 Watts)
