+ 4.09” Bar Capacity
+ 24” Swing Diameter over Bedways
+ 60” Between Centers
+ Compact Footprints make it ideal fo R&D and Toolroom shops
+ Easy to use Fanuc or Fagor CNC Control
+ Meehanite casting help minimize vibration for superior finish and tool life
CAPACITY & DIMENSIONS
Swing over Bed
24″ (610 mm)
Swing over Cross Slide
14.5″ (370 mm)
Center Height
12″ (305 mm)
Center Distance
59.05″ (1,500 mm)
Bed Length
102.36″ (2,600 mm)
Bed Way Width
15.75″ (400 mm)
Bed Casting Height
13 3/8″ (340 mm)
SPINDLE
Spindle Motor Horsepower
20 HP Peak (15 HP 30 min duty) (11 Kw – 15 Kw)
Spindle Speeds – Programmable
30 – 1,600 RPM infinitely variable, in 2 gear ranges
Spindle Speed 2 Gear Ranges – Programmable
M41 = 30 – 600 M42 = 80 – 1,600 RPM
Spindle Speed
H = 80 – 1,600 RPM L = 30 – 600 RPM
Spindle Bore
ø4.09″ (104 mm) (90 mm with hydraulic chuck)
Spindle Nose – Camlock
D1-8 Camlock 75 mm Draw tube
Spindle Bearings – 2 bearing spindle
Tapered Roller Bearings front, roller bearing rear
Spindle ID taper in spindle nose
MT-8 MT#8 Taper
CROSS SLIDE X AXIS
Rapid Traverse Feedrate
197 IPM (5 m / min)
X-Axis motor power
FANUC Beta IS4 0.75 Kw 4,000 RPM
Cross Slide Travel
12.63″ (320 mm)
Cross Slide Dimensions – width x length
9.05″ x 29.9″ (230 x 760 mm)
Cross Slide Ballscrew diameter
.984″ (25 mm)
Cross Slide Ballscrew Pitch
5 mm Accuracy Grade C3 (H-P Laser Tested)
Cross Slide Thurst
1,190 lbs (540 Kg Force)
CARRIAGE Z AXIS
Rapid Traverse Feedrate
197 IPM (5 m / min)
Z-Axis Motor Power
FANUC Beta IS4 0.75 kw (4,000 RPM)
Z-Axis Travel
59.05″ (1,500 mm)Cutting Tool Height Maximum
1″ (25 mm)
Carriage ballscrew diameter
1.26″ (32 mm)
Carriage ballscrew pitch
5 mm Accuracy Grade C3 (H-P Laser Tested)
Carriage Slide Thrust
1,190 lbs (540 kg Force)
TAILSTOCK
Quill Diameter
2.95″ (75 mm)
Quill Stroke – w/ selectable 2 speed Quill Advance
6.30″ (160 mm)
Quill Taper
MT-5 Morse Taper #5
Quill Tang Drive and drift-slot for tailstock
included
Tailstock body set-over adjustment
±0.4″ (±1 mm)
SPECIFICATIONS
Coolant Pump Motor
1/8 HP / 13.2 gal
Coolant Tank Capacity
10.5 gal (40 liters)
Electrical Requirements
220 vac ±5% 60 Hz / 75 amp service
Machine Weight
8,820 lbs (4,000 kgs)
Shipping Weight
9,260 lbs (4,200 kgs)
Machine Dimensions ( L x W x H )
129″ x 75″ x 80″ (3,260 x 1,900 x 2,030 mm)
Shipping Dimensions ( L x W x H )
133″ x 79″ x 86″
